Description
Product Description:
The atomizer atomizes the test solution. The atomizer is an important part of the atomization system, and its performance has a significant impact on the precision of the measurement and chemical interference. Therefore, the atomizer is required to have a stable spray, small, uniform and high atomization efficiency.
Mainly used to treat various upper and lower respiratory diseases, such as colds, fever, cough, asthma, sore throat, pharyngitis, rhinitis, bronchitis, pneumoconiosis and other diseases that occur in the trachea, bronchi, alveoli, and chest cavity. Nebulized inhalation therapy is an important and effective treatment method in the treatment of respiratory diseases. A nebulizer is used to atomize the liquid medicine into tiny particles, and the medicine enters the respiratory tract and lungs through breathing inhalation, so as to achieve painless , The purpose of rapid and effective treatment. The atomizer is suitable for children, children, the elderly, patients with special diseases, and adult students.
Product Features:
1) The fog is large, the atomized particles are fine, the particles can reach 0.5-5μm, and the drug absorption is more sufficient
2) Microporous spray sheet, atomization speed ≥0.2ml/min
3) The low-noise design is quieter through piezoelectric components
4) Residual drug solution ≤0.5ml, economical to use
5) Two atomization methods can be selected according to different situations, namely, mask atomization (divided into human and child masks) and mouthpiece atomization
6) The mask is comfortable, skin-friendly and environmentally friendly
7) Independent atomization components, easy to clean, one-click disassembly, easy to clean and disinfect, avoid cross-infection
8) When there is no liquid medicine in the cup or the voltage is insufficient, it will automatically shut down
9) Battery type: USB power cord or 2*1.5V (2 AA alkaline batteries, the product does not contain batteries)
Lithium battery: DC3.7V (two AA lithium batteries) or 5.0V USB power supply
Product Parameters:
Liquid cup capacity: 10ml (Max)
The type of security: internal power supply
The noise of the whole machine when the atomizer is working normally: 50DB (A-weighted).
Ultrasonic working frequency: 110KHZ±10KHZ.
Maximum atomization rate: 0.15ml/min - 0.90ml/min.
Medium particle size of the fog particles: The median diameter of the atomizer mist particles is 2.5μm, and the error should not
exceed ± 25%.
Water temperature in the atomizer sink: 60 ℃.
Equivalent volume particle size distribution: The fog particle diameter of 0.5 μm~ 5μm produced by the ultrasonic atomizer.
The proportion is greater than 60%.
